Einhell 40.104.40 Air Compressor 10 bar 50 Litres 240V
The Einhell TE-AC 270/50/10 compressor is an efficient and robust endurance runner for high requirements. The quality components and oil lubrication contribute to a very long life. The oil level can be conveniently checked through an inspection window. The working pressure of up to 10 bar can be set to many applications using the pressure reducer. Sufficient reserves of compressed air for every application are held ready by the 50-litre tank. The controlled working pressure of the TE-AC 270/50/10 can be monitored on the large pressure gauge and reduced at the quick-release coupling. A pressure gauge and a further quick-release coupling are also available for working with uncontrolled tank pressure. The practical drain plug for letting off the condensate enables user-friendly maintenance. A non-return valve and a safety valve ensure the safe operation of the TE-AC 270/50/10, while the large wheels and holding bar enable easy transport.
Features:
- Oil lubrication contributes to long life
- Oil level check through inspection window
- The 50l tank has sufficient air reserves
- Applications up to 10 bar can be set using the pressure reducer
- Pressure gauge & quick-release coupling for regulated pressure
- Pressure gauge & quick-release coupling for unregulated pressure
- Large wheels and transport bar for an easy transport
- Vibration-damped feet for standing securely
- Non-return valve, safety valve
- The drain plug enables user-friendly maintenance
Specification:
- Model: TE-AC270/50/10
- Item Number: 40.104.40
- Mains supply: 240V/50 Hz
- Max. engine power: 1800 W 2.5 PS
- Engine speed: 2850 min^-1
- Pump speed: 2850 min^-1
- Suction capacity: 270 L/min
- Output power at 0 bar: 140 L/min
- Output power at 4 bar: 127 L/min
- Output power at 7 bar: 100 L/min
- Max. operating pressure: 10 bar
- Tank volume: 50 L
- Length: 775 mm
- Width: 335 mm
- Height: 740 mm
- Weight: 33.5 kg
