Sealey MP408 Autel Maxiscope - Automotive Oscilloscope

Sealey Sealey MP408 Autel Maxiscope - Automotive Oscilloscope @11150

SKU
SEA-MP408
Only 1 left In Stock
£813.55 £677.96
Guaranteed In stock
  • Model No: MP408
  • Accessories (supplied): 1.5mtr USB Cable, 3mtr Screened Test Lead (x4), Secondary Ignition Pickup, 2-Pin Breakout Lead, Attenuators 20:1 (x2), Large Crocodile Clip Set (Pair), Small Crocodile Clip Set (Pair), Acupuncture Probe Set, Multimeter Probes (Pair)
  • Input:
  • Maximum Sample Rate: 80MS/s (Single Channel), 20MS/s (Multiple Channels)
  • Bandwidth: 20MHz
  • Input Range: 50mV - 100V (11 ranges)
  • Coupling: AC/DC
  • Impedance: 1M?
  • DC Accuracy: 1%
  • Input Protection: 200V
  • Timebase Range: 100ns/div - 1000s/div
  • Buffer Size: 32M shared on active channels
  • Sensitivity: 10mV/div - 20V/div
  • Trigger Type: Rising Edge, Falling Edge
  • Trigger Mode: Auto, Repeat, Single, None
  • Advanced Features: Math Channels, Measurements
  • Interface: USB 2.0
  • Operating System: Windows XP (SP3), Windows Vista, 7, 8 (32-bit or 64-bit)
  • Size: 190 x 115 x 38mm

Dispatched within 2 working days. Item is not available outside of the UK.

Details

Sealey MP408 Autel Maxiscope - Automotive Oscilloscope

Features:

  • 4-Channel automotive oscilloscope suitable for professional applications.
  • Works in conjunction with a MaxiSys® Model No's MS905 and MS908 Tablets to provide a powerful diagnostic tool.
  • Powered directly from a USB port, with no need for batteries or power leads, making it versatile and portable.
  • The 4-channel function allows multiple components to be compared simultaneously.
  • The scope is supplied with a wide selection of automotive type test leads, connectors and probes.
  • Accessories (supplied): 1.5mtr USB Cable, 3mtr Screened Test Lead (x4), Secondary Ignition Pickup, 2-Pin Breakout Lead, Attenuators 20:1 (x2), Large Crocodile Clip Set (Pair), Small Crocodile Clip Set (Pair), Acupuncture Probe Set, Multimeter Probes (Pair).
  • PC software can be downloaded from the Sealey or Autel website.

Comes With:

  • 1 Year Warranty

Specification

  • Model No: MP408
  • Accessories (supplied): 1.5mtr USB Cable, 3mtr Screened Test Lead (x4), Secondary Ignition Pickup, 2-Pin Breakout Lead, Attenuators 20:1 (x2), Large Crocodile Clip Set (Pair), Small Crocodile Clip Set (Pair), Acupuncture Probe Set, Multimeter Probes (Pair)
  • Input:
  • Maximum Sample Rate: 80MS/s (Single Channel), 20MS/s (Multiple Channels)
  • Bandwidth: 20MHz
  • Input Range: 50mV - 100V (11 ranges)
  • Coupling: AC/DC
  • Impedance: 1M?
  • DC Accuracy: 1%
  • Input Protection: 200V
  • Timebase Range: 100ns/div - 1000s/div
  • Buffer Size: 32M shared on active channels
  • Sensitivity: 10mV/div - 20V/div
  • Trigger Type: Rising Edge, Falling Edge
  • Trigger Mode: Auto, Repeat, Single, None
  • Advanced Features: Math Channels, Measurements
  • Interface: USB 2.0
  • Operating System: Windows XP (SP3), Windows Vista, 7, 8 (32-bit or 64-bit)
  • Size: 190 x 115 x 38mm
