Sealey TA330 Hand-held Automotive Single Channel Oscilloscope & Multimeter

SKU
SEA-TA330
£643.38
£536.15 ex. VAT

Out of stock

Sealey TA330 Hand-held Automotive Single Channel Oscilloscope & Multimeter

Features:

  • Simple to use oscilloscope that allows observation of constantly varying signals from vehicle components and sensors.
  • With a bandwidth of 20MHz the unit is suitable for detecting CAN signals on modern vehicles.
  • Functions include data hold, record and USB interface for downloading data to PC.
  • This versatile unit also has a built in multimeter with large digit display and bar graph.
  • Supplied with 3-pin UK and 2-pin European charger leads.

Comes With:

  • 1 Year Warranty

Specification:

  • Model No: TA330
  • Display: 320 x 240 pixel with LED Backlight
  • Bandwidth: 20MHz
  • Sample Rate: Maximum 80MSa/S
  • Input Impedance: 1M?
  • Maximum Input: 600V
  • Memory Capacity: 6 Waveforms
  • Trigger Mode: Auto, Normal, Single
  • Multimeter Modes: Voltage DC & AC, Current DC & AC, Resistance, Capacitance, Continuity, Diode
  • Battery: 3.7V Lithium Polymer
  • Operating Time: 3hr with Backlight
  • Size: 211 x 140 x 55mm
  • Weight: 700g
  • PC Compatibility: Windows 98, ME, 2000, XP, Win7, Vista
