Dewalt DWS780 305mm Compound Slide Mitre Saw with XPS 240V (Replaces DW718XPS)
TOOLSTOP Part No: DEW-DWS780-240V
Dewalt DWS780 305mm Compound Slide Mitre Saw with XPS
This new DWS780 mitre saw succeeds the highly popular DW718XPS and features increased capacity, a brighter XPS system, increased portability and better dust extraction
- Outstanding cutting performance in both small profiles and large construction timbers up to 110 x 303 mm
- XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity no adjustment required
- Heavy duty durability with the ability to fully adjust your machine to maintain accuracy over the life fo the tool.
- New quick release bevel stop setting provides accurate and simple setting of bevel angles up to 49° left and right
- Easy to use mitre and bevel controls making the tool fast and simple to change from one set up to another
- Cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly adjust angles between 0° - 50° left and 0° - 60° right
- Mitre lock system allows the user faster and easier to adjust angles between 0-50° left and 0-60 degrees to the left
- The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles
- Linear horizontal rails with bronze to provide maximum precision when cutting materials with width up to 345 mm to be cut
- Compact and lightweight design characteristics deliver a saw, it is easy to move around the workplace
- Very good dust control and støvblåsing away from work
- Electronic speed control for adjusting cutting speed when using the non-ferrous materials (material clamps should be used for cutting non-ferrous materials
- The unique depth stop allows the saw can also be used to track and false work
- High Quality 60 tooth blade
- Blade spanner
- Dust bag
- Material Clamp
- 1 year Manufacturers warranty
**images for illustrative purposes only – please refer to description and specification for full details of product
- Barcode: 5035048332320
- Power Input: 1675 Watts
- Power Output: 960 Watts
- Blade Speed: 1900 - 3800 rpm
- Blade Diameter: 305mm
- Blade Bore: 30mm
- Bevel Capacity: 49/49°
- Mitre Capacity right: 60°
- Mitre Capacity left: 50°
- Cutting Capacity at 90°/90°: 303 x 110 mm
- Cutting Capacity at 90°/90°: 345 x 76 mm
- Cutting Capacity at 45°/90°: 268 x 63 mm
- Cutting Capacity at 45°/90°: 345 x 44 mm
- Cutting Capacity at 90°/45°: 211 x 112 mm
- Cutting Capacity at 90°/45°: 244 x 76 mm
- Max Capacity 45°/45°: 212 x 76 mm
- Depth: 470mm
- Length: 770mm
- Height: 396mm
- Total Shipping Weight: 40kg
