SIP 05702 T113 ARC/TIG Inverter Welder

SKU: SIP-05702

SIP

SIP 05702 T113 ARC/TIG Inverter Welder

The T113 ARC/TIG Inverter Welder from SIP is equipped with a Voltage Reduction Device - for added safety, dinse sockets, anti-stick circuitry and utilise a Lift-TIG start function. Supplied with an electrode holder/cable plus Earth cable and clamp.

Features:

240V (13amp) supply
1.6mm - 2.5mm electrode size
20amps - 100amps (peak) current range
1.5mm - 5.0mm approx. weld thickness (mild steel)
VRD - Voltage Reduction Device
Lift-TIG function included
Thermal overload protection
High portability & lightweight

Comes with:

Electrode holder/cable
Earth cable
Clamp

Specification:

Supply: 240v (13amp)
Open Circuit Voltage: 78v
Electrode Size: 1.6 - 2.5mm
Current Range: 20 - 100amps
Welding Voltage (MMA): 20.8v - 24v
Welding Voltage (TIG): 10.8v - 14v
Approx. Weld Thickness: 1.5 - 5.0mm (mild steel)
Duty Cycle: 100amps @ 20%, 58amps @ 60%, 45amps @ 100%
Power Factor: 0.65
Efficiency: 85%
Insulation Class: H
Protection: IP21S
Net Weight: 4.5kg
Product Dimensions: 255 x 120 x 380mm
Additional: Generator friendly
