Fluke 114 Electrical Multimeter (2583552)

Fluke 114 Electrical Multimeter (2583552)

The Fluke 144 is a compact true-rms multimeter for electrical troubleshooting with easy one-handed operation and automatic AC/DC selection. The Fluke 114 is the tool for "go/no-go" testing. It includes a feature to prevent false readings caused by ghost voltage. Digital multimeters give electricians, HVAC engineers and inspectors exactly what they need: accurate measurements, consistent reliable performance, and safe operation. All our meters are tested to the extreme for drop, shock and humidity.

Features:

• AutoVolt: automatic ac/dc voltage selection
• Large white LED backlight to work in poorly lit areas
• Resistance and continuity
• Min/Max/Average to record signal fluctuations
• CAT III 600 V safety rated
• All inputs are protected to CE, IEN61010-1 CAT III 600V

Specification:

• Maximum voltage between any terminal and earth ground: 600 V
• Surge protection: 6 kV peak per IEC 61010-1 600 VCAT III, Pollution Degree 2
• Display Digital: 6,000 counts, updates 4 per second
• Bar graph: 33 segments, updates 32 per second
• Operating Temperature: -10°C to + 50°C
• Storage Temperature: -40°C to + 60°C
• Battery type: 9 volt Alkaline, NEDA 1604A/ IEC 6LR61
• Battery Life: 400 hours typical, without backlight
• Size: 167 x 84 x 46 mm (6.57" x 3.31" x 1.82")
• Weight: 0.55kg

SKU: FLU-114
