The Sealey LH1500 Lever Hoist Steel is equipped with a heavy-duty brake
The Sealey LH1500 is a 1500kg Lever Hoist Steel equipped with a heavy-duty brake and a high-quality alloy steel chain for durable and safe operation. Its rugged construction features drop-forged and heat-treated pinion gear with totally enclosed mechanisms. The free-chaining feature permits slack in the load chain to be taken up by hand before engaging the ratchet arm.
Features:
- Equipped with heavy-duty brake and high-quality alloy steel chain for durable and safe operation
- Free-chaining feature permits slack in the load chain to be taken up by hand before engaging the ratchet arm
- Rugged construction features drop-forged and heat-treated pinion gear with totally enclosed mechanisms
Specification:
- Chain Falls: 1
- Weight: 12kg
- Capacity: 1500kg
- Test Load: 2250kg
- Model No: LH1500
- Chain Length: 1.5m
- Load Chain ∅: 8mm
- Head Room: 295mm
- Lever Length: 410mm
- Hook Aperture: 30mm
- Overall Depth: 172mm
- Overall Width: 160mm
- Operating Clearance: 104mm
- Maximum Hook Capacity ∅: 45mm
- Pull on Lever to Lift Full Load: 24kgf
