Trend Diamond Sharpening DWS/HG/SET Diamond Honing Guide Set

SKU
TRE-DWS/HG/SET
£45.00
£37.50 ex. VAT

Out of stock

Trend DWS/HG/SET Diamond Honing Guide Set

The Trend DWS/HG/SET diamond honing guide set will ensure that you maintain the correct angle on chisels and plane irons. The setting device is preset for 25 degree, 30 degree, 35 degree and 40 degree angles

Features:

  • Ensures correct primary angle is maintained on bevel edge chisels and plane irons when used with diamond whetstone
  • Precision roller with alloy body which self-centre clamps bevel edge chisels from 3/8 inch (10mm) to 1-1/4 (32mm) and plane irons up to 2-3/8 inch (60.3mm) wide. Maximum tool thickness 7mm
  • Positive location for roller and blade
  • Adjustable stop for setting blade angle
  • Use with 63mm (2 1/2 inch) wide x 178mm (7 inch) long bench stones or workshop stones
  • Not for use with Firmer chisels or short blade (Butt) chisels
  • Warranty: 12 months

Comes With:

  • 1 x Diamond honing guide
  • 1 x Diamond honing guide setting device

Specification:

  • Chisel blade width min.:10 mm
  • Chisel blade width max.:32 mm
  • Chisel blade thickness max.:7 mm
  • Chisel blade length min.75 mm*
  • Plane blade width max.:60.3 mm
  • Angle:25 deg, 30 deg, 35 deg & 40 deg
  • *at 25 deg
  • Nett Weight: 0.407 Kg
  • Packaged Size: 160x95x40mm
