Norbar 13052 Torque Wrench Production P-Type Industrial Ratchet (Push Through Square) Model 60, 1/2in, 8 - 60N.m

SKU
NOR-13052
£79.00
£65.83 ex. VAT

Norbar 13052 Torque Wrench Production P-Type Industrial Ratchet (Push Through Square) Model 60, 1/2", 8 - 60N.m, comes in a moulded box for storage and protection

'P' Type Torque Wrenches are designed for the production environment where they will be set and then dedicated to a particular application. There is no scale, the wrench must be set against a torque testing device such as Norbar's Professional Torque Tester. The push-through ratchets on these models are robustly engineered for strength and durability. The strength and high wear resistance comes from a coarse tooth pattern while a principle of offset ratchet pawls gives a narrow engagement angle. The push-through square drive is not only a robust design but allows the wrench to be used for torque control in both the clockwise and anti clockwise directions, and allows for a wider model range of up to 400 N-m.

Features:

  • Setting system is designed to discourage unauthorised alteration
  • Coloured end seals are provided to identify the wrench to a particular operator, torque setting or calibration period
  • Accuracy of +/-3% of reading exceeds all international standards for torque wrenches
  • Available with a high quality ratchet or as a 'Torque Handle'
  • Retained square drive will not pull out of the head when the socket is removed

Comes With:

  • Plastic storage case
  •

Specification:

  • Length: 299 mm
  • Ratchet Diameter: 40 mm
  • Ratchet Type: Industrial Push-Through
  • Reaction Plate Weight: 72
  • Square Size: 1/2"
  • Accuracy: +/-3%
  • Operates between:
  • 500.0 - 900.0 lbf-in
  • 5.0 - 45.0 lbf-ft
  • 8.0 - 60.0 N-m
  • 1.0 - 6.0 kgf-m
  • Weight: 0.69 Kg
