Trend CRB 7-Function Combination Router Base

Trend CRB 7-Function Combination Router Base

A must for any tradesman doing router jobs, the CRB Combination Router Base from Trend is a multi-function, quick-change device designed for attaching to many routers and is able to:

• Increase the overall versatility of the router
• Improve the quality of finish of every routing pass
• Reduce the possibility of error
• Increase stability during routing
• Increase the level of precision achieved
• Save set up time between tasks
• Save space on storing hand made jigs
• The CRB has seven functions:
• - an offset baseplate
• - router compass from 19mm to 224mm radius
• - adjustable trenching with a clamp guide with 40mm micro adjustment
• - adjustable anti-tilt support
• - adjustable mortising of timber from 50mm to 200mm width
• - adjustable false panel groove copier
• - enhances the Varijig frame system as an anti-tilt device when used with routers that can accept Euro style guide bushes (a special guide bush part number: GB40/B is required)
• The CRB will fit most routers with two 8mm, 10mm and 12mm fence rod holes at centres of 78mm to 130mm
• An accessory quick fit edge trimming base is available for trimming lipping up to 16mm wide and 6mm projection, part number: CRB/TB
• Larger circles can be accommodated by using accessory extension rods - part number: N/COMPASS/AEX to increase the radius by 560mm

Comes with:

• 1 x Plastic baseplate with handle
• 1 x Bridge
• 2 x Rods 8mm dia x 270mm
• 1 x Bridge shim pack (2x2mm, 1x2mm, 1x1mm, 1x0.5mm)
• 1 x Scale
• 1 x Pivot pin
• 1 x Pair of mortise pillars

Specification:

• Rod size 8 mm
• Rod centres 78 mm to 130 mm
• Mortising width min. 50 mm
• Mortising width max. 200 mm
• Anti-tilt height max. 80 mm
• Anti-tilt height min. 8 mm
• Lateral adjustment of 110 mm
• Micro adjustment 40 mm
• One revolution 1.25 mm
• Circle dimensions using 6.35mm cutter and measured from the outside edge of hole:
• Circle radius min. 19 mm
• Circle diameter min. 38 mm
• Circle radius max. 224 mm
• Circle diameter max. 448 mm
• Length 285 mm
• Width 175 mm
• Thickness 5 mm
• Cutter diameter max. possible 40 mm. Please refer to router manufacturers specification
• Net Weight: 1.196kg

SKU: TRE-CRB
